Introducing the M8 male straight, 3-pole plastic assembly connector with threaded joint and screw terminals. Made with PVC/TPU for robust connections, it offers IP67/IP68 protection. Compatible with Ø 3.5-5.0 mm cables, it excels in harsh environments. At V5 GROUP - VIDIA LTD., we provide top industrial automation solutions. Choose EAM8MCW3001A for reliable performance and quality.

EAM8MCW3001A

Name: EAM8MCW3001A
Brand: V5 GROUP
SKU: Sensor Connector
Price: 46 ILS
Availability: InStock

SKU: Sensor Connector

₪46.00

Connector size:

Connector type:

Number of pins:

Connection angle:

Cable size compitability:

Max. Voltage \ Current:

Quantity

TECHNICAL INFORMATION:

Shell material	Brass nickel-plated/Zinc alloy nickel-plated
Sealing material	Epoxy resin/Rubber
Contact material	Brass/Phosphorus copper gold-plated
Insulator material	PA66
Molding material	TPU/PVC
Contact impedance	≤5mΩ
Cable diameter	Ø 3.5-5.0 mm
Insulation impedance	≥100MΩ
Work temperature	-25℃ ~ +80℃
Waterproof grade	IP65/IP67

ELECTRICAL SPECIFICATIONS

Max. current	1A
Voltage	60V ( AC / DC )
Compatible for cable size	24 AWG / 0.25 mm²
Compatible for cable matereal	PVC/PUR

EAM8MCW3001A

Technical Specifications

Download product user manual

Download product brochure

Download product drawing

Download accesorie bracket drawing
